Bullit R
Build Kit & Specs
*Please note: we make every effort to ensure accuracy of spec information, but they are subject to change.
| Frame | |
|---|---|
| Material | |
| Features | |
| Suspension | |
| Fork | |
| Shock | |
| Drivetrain | |
| Rear Derailleur | |
| Shifter | |
| Crankset | |
| Cassette | |
| Chain | |
| Bottom Bracket | |
| Brakes | |
| Brakes | |
| Front Rotor | |
| Rear Rotor | |
| Cockpit | |
| Handlebars | |
| Stem | |
| Grips | |
| Headset | |
| Seatpost | |
| Saddle | |
| Wheels | |
| Front Rim | |
| Front Hub | |
| Front Tire | |
| Rear Rim | |
| Rear Hub | |
| Rear Tire | |
| Valves | |
| Ebike | |
| Battery | |
| Drive Unit | |
| Specs | |
| Headset | |
| Seat Post Diameter | |
| Seat Clamp Diameter | |
| Rear Brake Mount | |
| Bottom Bracket Shell | |
| Max Tire Clearance | |
| Max Chainring Size | |
| Water Bottle Mounts | |
| Shock Length | |
| Shock Stroke | |
| Shock Bushing Sizes | |
| Shock Bushing Sizes | |
| Shock Mounting Hardware Upper | |
| Shock Mounting Hardware Lower | |
| Fork Offset |
Bullit R
Sizing & Geometry
If you're on the cusp between the recommended height range of two sizes, the absolute best thing is to try to ride them both. At a minimum, check the stack/reach measurements on your current bike and compare it to the new model you are looking at to get an idea of a fit you are already comfortable with. If riding the bike is not an option, consider the following.
| m | l | xl | xxl | |
|---|---|---|---|---|
| A. Reach | 450 | 475 | 495 | 515 |
| B. Stack | 621 | 630 | 648 | 670.4 |
| Head tube angle | 64° | 64° | 64° | 64° |
| L. Seat Tube Length | 405 | 430 | 460 | 500 |
| F. Front Center | 789.4 | 818.8 | 847.5 | 878.5 |
| H. BB Height | 348 | 348 | 348 | 348 |
| I. BB Drop | 25.5/6.5 | 25.5/6.5 | 25.5/6.5 | 25.5/6.5 |
| E. Wheelbase | 1238.5 | 1267.9 | 1296.7 | 1327.7 |
| G. Rear Center | 449 | 449 | 449 | 449 |
| K. Head Tube Length | 100 | 110 | 130 | 155 |
| M. Top Tube Length | 591.3 | 619.2 | 644.9 | 672.1 |
| D. Seat Tube Angle | 77.2° | 77.1° | 77° | 76.8° |
| J. Standover Height | 748 | 747 | 745 | 745 |
Bullit R
Setup & Support
Whether you’re the proud owner of a Bullit or are just digging deep into the details you’ll find it all here.
| Rider weight lbs | Rider weight kgs | Pressure | Rebound single |
|---|---|---|---|
| 100 | 45 | 39 | 13 |
| 120 | 54 | 47 | 12 |
| 140 | 64 | 55 | 11 |
| 160 | 73 | 64 | 11 |
| 180 | 82 | 72 | 10 |
| 200 | 91 | 80 | 9 |
| 220 | 100 | 88 | 8 |
| Rider weight lbs | Rider weight kgs | Pressure | Sag | Rebound single |
|---|---|---|---|---|
| 100 | 45 | 100 | 29-32%, 18-20mm | 7 |
| 120 | 54 | 125 | 29-32%, 18-20mm | 7 |
| 140 | 64 | 145 | 29-32%, 18-20mm | 7 |
| 160 | 73 | 170 | 29-32%, 18-20mm | 6 |
| 180 | 82 | 190 | 29-32%, 18-20mm | 6 |
| 200 | 91 | 215 | 29-32%, 18-20mm | 6 |
| 220 | 100 | 235 | 29-32%, 18-20mm | 5 |
| 240 | 109 | 260 | 29-32%, 18-20mm | 5 |
| 260 | 118 | 280 | 29-32%, 18-20mm | 5 |
| label | name | quantity | part_number | blurb | torque |
|---|---|---|---|---|---|
| A | 67-19217 | 1 | Head Tube Badge | Clean frame surface, center on headtube | |
| B | 72-21292 | 1 | Shimano BM-E8030 | For EP801 use battery mount BM-EN801 (72-24168) | |
| C | 78-21554 | 1 | Shimano BT-E8036 | For EP801 use battery BT-EN806 (78-24169) | |
| D | 26-18382 | 6 | M4x12 BHCS | Apply grease to treads | 0.65 Nm |
| E | 30-22329 | 1 | Bullit 3C battery cover | ||
| F | 26-15939 | 2 | M3x12 BHCS | Apply Loctite 242 to threads | 0.1 Nm |
| G | 30-22358 | 1 | DU Protector | ||
| H | 26-22358 | 1 | M3x6 | Apply Loctite 242 to threads | 0.6 Nm |
| I | 26-19207 | 2 | Hose Grommet | ||
| J | 34-20201 | 2 | 36.4 Seat Collar |
| label | name | quantity | torque | part_number | blurb |
|---|---|---|---|---|---|
| A | 26-20122 | 2 | 16 Nm | M10x23 Screw | Apply Loctite 242 to threads only, apply grease to shaft only |
| B | 26-21360 | 2 | Water Bottle Screw | ||
| C | 08-22343 | 2 | 20 Nm | Pivot Axle M15x91 | Apply Loctite 242 to threads only, apply grease to shaft only |
| D | 26-15633 | 3 | M6 Tapered Washer | Apply grease to surface | |
| E | 26-11817 | 3 | M6 Washer | ||
| F | 26-15947 | 3 | 9 Nm | M6x20 SHCS | Apply Loctite 242 to threads |
| G | 26-21231 | 1 | 22 Nm | M8x50 Shock Bolt | Apply loctite 242 to threads |
| H | 72-21270 | 1 | Shimano EW-CP100 | Charge port for EP8 & EP801 | |
| I | 26-15939 | 2 | 0.1 Nm | M3x12 BHCS | Apply Loctite 242 to threads |
| J | 26-21223 | 1 | 12.5 Nm | M8x20 BHCS | Apply Loctite 242 to threads |
| K | 72-21559 | 1 | Shimano DC-EP800 | For EP801 use DC-EP801 (72-24172) | |
| L | 08-20879 | 1 | 20 Nm | Pivot Axle M15x72 | Apply Loctite 242 to threads only, apply grease to shaft only |
| M | 26-21231 | 1 | 22 Nm | M8x50 Shock Bolt | Apply loctite 242 to threads |
| label | name | quantity | part_number | blurb | torque |
|---|---|---|---|---|---|
| A | 08-22209 | 1 | Rear axle 12x173.7 | Apply grease to shaft and threads | |
| B | 23-23491 | 1 | SCB UDH | Interchangeable with Sram UDH | |
| C | 26-23492 | 1 | SCB UDH screw | Reverse thread | 20 Nm |
| D | 30-21226 | 1 | Chainstay Protector | ||
| E | 26-15939 | 1 | M3x12 BHCS | Apply Loctite 242 to threads | 0.1 Nm |
| F | 30-20189 | 1 | Chainstay Protector | ||
| G | 26-21223 | 3 | M8x20 BHCS | Apply Loctite 242 to threads | 12.5 Nm |
| H | 26-18382 | 2 | M4x12 BHCS | Apply grease to treads | 0.65 Nm |
| I | 49-21567 | 1 | Lower Link Fender | ||
| J | 30-21453 | 1 | Seatstay Protector | ||
| K | 26-21361 | 1 | Hose Grommet Single | ||
| L | 26-15939 | 1 | M3x12 BHCS | Apply Loctite 242 to threads | 0.1 Nm |
| M | 72-22286 | 1 | Shimano Speed Sensor | Use for both EP8 & EP801 |
| label | name | quantity | part_number | blurb |
|---|---|---|---|---|
| A | 29-22342 | 1 | Upper Link | |
| B | 11-12681 | 2 | 6900-2RS Bearing | |
| C | 26-15533 | 2 | M10x3 Washer | Apply grease to inner surface |
| D | 26-11612 | 2 | Bearing Dust Shield | Apply grease to inner surface |
| E | 11-12218 | 2 | 6902-2RS Max Bearing | |
| F | 26-17013 | 1 | 15x40.25 Bearing Spacer |
| label | name | quantity | part_number | blurb | torque |
|---|---|---|---|---|---|
| A | 29-22341 | 1 | Lower Link | ||
| B | 11-17708 | 4 | 6902-1ZR Bearing | ||
| C | 26-11612 | 4 | Bearing Dust Shield | Apply grease to inner surface | |
| D | 26-20880 | 1 | 15x32 Bearing Spacer | ||
| E | 26-17707 | 1 | 15x48 Bearing spacer | ||
| F | 26-12678 | 1 | M6 Grease Fitting | 9 Nm | |
| G | 26-15532 | 1 | M5x5 Set Screw | Apply Loctite 242 to threads, titghten until flush | 0.5 Nm |
