Hightower 3 MY23
Model Specs
| Suspension System | VPP |
|---|---|
| Front Derailleur | No compatibility |
| Headset | Integrated (IS41/52) |
| Seat Post Diameter | 31.6mm |
| Seat Clamp Diameter | 36.4mm |
| Shock Length | 210mm |
| Shock Stroke | 55mm |
| Fork Compatibility | 150-160mm |
| Fork Offset | 44mm |
| Rear Brake Mount | 180 PM |
| Bottom Bracket Shell | 73mm Threaded |
| Max Tire Clearance | 2.5" |
| Max Chainring Size | 34t |
| Water Bottle Mounts | 1 |
| Shock Bushing Sizes | 30x8 |
| Shock Bushing Sizes | 30x8 (bearing compatible) |
Build Kits
Select a Build Kit
| Weight | 32.02 lbs / 14.52 kg |
|---|---|
| Material | Carbon C |
| Shock | FOX Float Performance DPS 210x55 |
| Fork | RockShox Lyrik Base, 150mm |
| Rear Derailleur | SRAM NX Eagle, 12spd |
| Translation missing: it.products.product.specs.shifters | SRAM NX Eagle, 12spd |
| Cassette | SRAM PG1230, 12spd, 11-50t |
| Chain | SRAM NX Eagle, 12spd |
| Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
| Headset | Cane Creek 10 IS Integrated Headset |
| Rear Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxTerra, EXO, TR |
| Front Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR |
| Translation missing: it.products.product.specs.sealant | Reserve Tubeless Sealant |
| Front Hub | SRAM MTH 716, 15x110, Torque Cap, 32h |
| Front Rim | RaceFace AR Offset 30 29" |
| Rear Hub | SRAM MTH 746, 12x148, 32h |
| Rear Rim | RaceFace AR Offset 30 29" |
| Front Rotor | Avid Centerline 180mm |
| Rear Rotor | Avid Centerline 180mm |
| Brakes | SRAM G2 R |
| Crankset | SRAM Descendant Eagle 148 DUB 30t |
| Handlebars | RaceFace Aeffect R, 780mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Saddle | WTB Silverado Medium CroMo |
| Seatpost | SDG Tellis Dropper, 31.6 |
| Grips | Santa Cruz Bicycles House Grips |
| Travel | 150/145mm |
| Wheel Size | 29" |
| Weight | 31.98 lbs / 14.51 kg |
|---|---|
| Material | Carbon C |
| Shock | Rockshox Super Deluxe Select+ 210x55 |
| Fork | FOX 36 Float Performance, 150mm |
| Rear Derailleur | SRAM GX Eagle, 12spd |
| Translation missing: it.products.product.specs.shifters | SRAM GX Eagle, 12spd |
| Cassette | SRAM XG1275 Eagle, 12spd, 10-50t |
| Chain | SRAM GX Eagle, 12spd |
| Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
| Headset | Cane Creek 40 IS Integrated Headset |
| Rear Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxTerra, EXO, TR |
| Front Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR |
| Translation missing: it.products.product.specs.sealant | Reserve Tubeless Sealant |
| Front Hub | DT Swiss 370, 15x110, 28h |
| Front Rim | RaceFace AR Offset 30 29" |
| Rear Hub | DT Swiss 370, 12x148, XD, 36t, 28h |
| Rear Rim | RaceFace AR Offset 30 29" |
| Front Rotor | Avid Centerline 180mm |
| Rear Rotor | Avid Centerline 180mm |
| Brakes | SRAM Code R |
| Crankset | SRAM GX Eagle 148 DUB 30t |
| Handlebars | Burgtec RideWide Alloy Bar, 800mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Saddle | WTB Silverado Medium CroMo |
| Seatpost | SDG Tellis Dropper, 31.6 |
| Grips | Santa Cruz Bicycles House Grips |
| Travel | 150/145mm |
| Wheel Size | 29" |
| Weight | 31.72 lbs / 14.39 kg |
|---|---|
| Material | Carbon C |
| Shock | Rockshox Super Deluxe Select+ 210x55 |
| Fork | FOX 36 Float Performance Elite, 150mm |
| Rear Derailleur | SRAM GX AXS Eagle, 12spd |
| Translation missing: it.products.product.specs.shifters | GX AXS Controller w/ Rocker Paddle |
| Cassette | SRAM XG1275 Eagle, 12spd, 10-50t |
| Chain | SRAM GX Eagle, 12spd |
| Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
| Headset | Cane Creek 40 IS Integrated Headset |
| Rear Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxTerra, EXO, TR |
| Front Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR |
| Translation missing: it.products.product.specs.sealant | Reserve Tubeless Sealant |
| Front Hub | i9 1/1, 15x110, 28h |
| Front Rim | RaceFace ARC Offset 30 29" |
| Rear Hub | i9 1/1, 12x148, XD, 28h |
| Rear Rim | RaceFace ARC Offset 30 29" |
| Front Rotor | Avid Centerline 180mm |
| Rear Rotor | Avid Centerline 180mm |
| Brakes | SRAM Code RS |
| Crankset | SRAM GX Eagle 148 DUB 32t |
| Handlebars | Santa Cruz 35 Carbon Bar, 800mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Saddle | WTB Silverado Medium CroMo |
| Seatpost | RockShox Reverb Stealth, 31.6 |
| Grips | Santa Cruz Bicycles House Grips |
| Travel | 150/145mm |
| Wheel Size | 29" |
| Weight | 31.62 lbs / 14.34 kg |
|---|---|
| Material | Carbon C |
| Shock | Rockshox Super Deluxe Select+ 210x55 |
| Fork | FOX 36 Float Performance Elite, 150mm |
| Rear Derailleur | SRAM GX AXS Eagle, 12spd |
| Translation missing: it.products.product.specs.shifters | GX AXS Controller w/ Rocker Paddle |
| Cassette | SRAM XG1275 Eagle, 12spd, 10-50t |
| Chain | SRAM GX Eagle, 12spd |
| Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
| Headset | Cane Creek 40 IS Integrated Headset |
| Rear Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxTerra, EXO, TR |
| Front Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR |
| Translation missing: it.products.product.specs.sealant | Reserve Tubeless Sealant |
| Front Hub | i9 1/1, 15x110, 28h |
| Front Rim | Reserve 30|HD 29", 28h |
| Rear Hub | i9 1/1, 12x148, XD, 28h |
| Rear Rim | Reserve 30|HD 29", 28h |
| Front Rotor | Avid Centerline 180mm |
| Rear Rotor | Avid Centerline 180mm |
| Brakes | SRAM Code RS |
| Crankset | SRAM GX Eagle 148 DUB 32t |
| Handlebars | Santa Cruz 35 Carbon Bar, 800mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Saddle | WTB Silverado Medium CroMo |
| Seatpost | RockShox Reverb Stealth, 31.6 |
| Grips | Santa Cruz Bicycles House Grips |
| Travel | 150/145mm |
| Wheel Size | 29" |
| Weight | 31.09 lbs / 14.1 kg |
|---|---|
| Material | Carbon CC |
| Shock | Rockshox Super Deluxe Ultimate 210x55 |
| Fork | FOX 36 Float Factory, 150mm |
| Rear Derailleur | SRAM X01 Eagle, 12spd |
| Translation missing: it.products.product.specs.shifters | SRAM X01 Eagle, 12spd |
| Cassette | SRAM XG1275 Eagle, 12spd, 10-50t |
| Chain | SRAM GX Eagle, 12spd |
| Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
| Headset | Cane Creek 40 IS Integrated Headset |
| Rear Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxTerra, EXO, TR |
| Front Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR |
| Translation missing: it.products.product.specs.sealant | Reserve Tubeless Sealant |
| Front Hub | i9 1/1, 15x110, 28h |
| Front Rim | RaceFace ARC Offset 30 29" |
| Rear Hub | i9 1/1, 12x148, XD, 28h |
| Rear Rim | RaceFace ARC Offset 30 29" |
| Front Rotor | Avid Centerline 180mm |
| Rear Rotor | Avid Centerline 180mm |
| Brakes | SRAM Code RSC |
| Crankset | SRAM X1 Eagle Carbon 148 DUB 32t |
| Handlebars | Santa Cruz 35 Carbon Bar, 800mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Saddle | WTB Silverad Medium Ti |
| Seatpost | RockShox Reverb Stealth, 31.6 |
| Grips | Santa Cruz Bicycles House Grips |
| Travel | 150/145mm |
| Wheel Size | 29" |
| Weight | 30.88 lbs / 14.01 kg |
|---|---|
| Material | Carbon CC |
| Shock | Rockshox Super Deluxe Ultimate 210x55 |
| Fork | FOX 36 Float Factory, 150mm |
| Rear Derailleur | SRAM X01 Eagle AXS, 12spd |
| Translation missing: it.products.product.specs.shifters | GX AXS Controller w/ Rocker Paddle |
| Cassette | SRAM XG1275 Eagle, 12spd, 10-50t |
| Chain | SRAM GX Eagle, 12spd |
| Bottom Bracket | SRAM DUB 68/73mm Threaded BB |
| Headset | Cane Creek 40 IS Integrated Headset |
| Rear Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxTerra, EXO, TR |
| Front Tire | Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, TR |
| Translation missing: it.products.product.specs.sealant | Reserve Tubeless Sealant |
| Front Hub | i9 1/1, 15x110, 28h |
| Front Rim | Reserve 30|HD 29", 28h |
| Rear Hub | i9 1/1, 12x148, XD, 28h |
| Rear Rim | Reserve 30|HD 29", 28h |
| Front Rotor | Avid Centerline 180mm |
| Rear Rotor | Avid Centerline 180mm |
| Brakes | SRAM Code RSC |
| Crankset | SRAM X1 Eagle Carbon 148 DUB 32t |
| Handlebars | Santa Cruz 35 Carbon Bar, 800mm |
| Stem | Burgtec Enduro MK3, 42mm |
| Saddle | WTB Silverad Medium Ti |
| Seatpost | RockShox Reverb Stealth, 31.6 |
| Grips | Santa Cruz Bicycles House Grips |
| Travel | 150/145mm |
| Wheel Size | 29" |
| Weight | 6.36 lbs / 2.89 kg |
|---|---|
| Material | Carbon CC |
Geometry
All units are in millimeters or degrees.
| s | m | l | xl | xxl | |
|---|---|---|---|---|---|
| A. Reach (Hi/Lo) | 430/427 | 455/452 | 475/472 | 495/492 | 520/517 |
| B. Stack (Hi/Lo) | 611/613 | 625/627 | 634/636 | 652/654 | 665/668 |
| C. Head Tube Angle (Hi/Lo) | 64.8°/64.5° | 64.8°/64.5° | 64.8°/64.5° | 64.8°/64.5° | 64.8°/64.5° |
| D. Seat Tube Angle (Hi/Lo) | 77°/76.7° | 77°/76.7° | 76.7°/76.4° | 76.9°/76.6° | 76.9°/76.7° |
| E. Wheelbase (Hi/Lo) | 1183/1183 | 1217/1218 | 1244/1245 | 1276/1276 | 1310/1311 |
| F. Front Center (Hi/Lo) | 752/752 | 783/783 | 807/807 | 836/836 | 867/867 |
| G. Rear Center (Hi/Lo) | 431/432 | 434/435 | 437/438 | 440/441 | 443/444 |
| H. BB Height (Hi/Lo) | 342/339 | 342/338 | 342/338 | 342/338 | 342/338 |
| I. BB Drop (Hi/Lo) | 31/34 | 31/34 | 31/34 | 31/34 | 31/34 |
| J. Standover Height (Hi/Lo) | 706/701 | 708/703 | 711/706 | 714/709 | 719/714 |
| K. Head Tube Length | 100 | 115 | 125 | 145 | 160 |
| L. Seat Tube Length | 380 | 405 | 430 | 460 | 500 |
| M. Top Tube Length (Hi/Lo) | 571/572 | 599/600 | 626/627 | 647/648 | 674/675 |
